| Construction | Premium, Durable Casing – Industrial Grade |
|---|---|
| Fire Control Panel Interfacing | Each Device can be interfaced with fire control panel with the output module. Several devices can be connected at cascade combination (256 Emergency Light Device per loop) |
| Fire Panel interfacing | Isolated with Output Module |
| Fire Input Signal | 6V to 24V DC Peak |
| Fire Output Signal | 6V Peak |
| Isolation | Full Isolation between fire panel Lycan 7559 Light module |
| Signal Transmission | Wired or Wireless |
| Stand by Power | 85-265V, 200mA with 2-3-Watt input Power with Built in AC Charger. |
| Function | Auto light ON during power failure. After 3 hrs of illumination the microprocessor will automatically turnoff the LED Light for longer Battery Life and the circuit is capable for re-triggering for second time illumination for 2 hrs+ |
| Switch and Fuse | Test Switch and 5A Fuse, AC Indicator LED, Full Charge LED and FIRE Alarm LED, FIRE IN/OUT PORT |
| Microcontroller Use | PIC18F Series 16 MHz |
| Battery | 6V-4.5AH Heavy Duty LEAD-ACID Battery 500 Charging Cycle+ |
| LED Lamp | 24Watt LED Light output (12W SMD*2) |
| Auto Shutdown | LED Light turns off automatically after 3Hrs which provides longer life for both battery and Product |
| Full Discharge Backup | 6-7 Hours |
| Luminous Intensity | 70-80 Lux illumination at 10 ft distance from headlight |
| Luminous Flux | 120 Lumen/Watt |
| Light Color | 3500K Yellow Light |
| Battery Charger | Inbuilt Float and Trickle Charging Method with Auto Cut-off |
| Protection | Overcharge, Over-Discharge, Surge Protection, Soft Startup, BMS |
| Certificate | UL Standard, NFPA Compliant, Accord Standard, BUET Tested |
| Expected Lifetime | 4-5 Years |
The ORASKA Lycan7559 is a next-generation Fire-Synchronized Emergency Fog Light, specifically designed to ensure uninterrupted visibility during critical fire or power failure scenarios.
This unit activates under two distinct conditions:
Power Failure:
– The light automatically turns on when AC power is lost, serving as a standard emergency light.
Fire Detection (Even if AC is ON):
– If any smoke detector linked to the fire control panel detects fire or smoke, the control panel sends a command and the device instantly turns on, regardless of AC power availability.
This dual-mode functionality ensures fail-safe protection even if the building’s backup systems are still running — delivering reliable, high-visibility fog lighting in real emergencies.
Directly connects to the fire control panel’s output module
If any smoke or heat detector triggers, the panel activates all connected Lycan7559 units in cascade mode
Lights turn on simultaneously across large areas, offering uniform visibility for evacuation and emergency access
Critical for identifying smoke/fog origin points and guiding safe exits
24W High-Intensity Yellow LED
Specialized 3500K fog-cutting beam enhances vision in smoke or haze
Gentler on eyes than white light, aiding safer evacuation
Designed for factories, storage zones, basements, and smoke-prone areas
Built-in intelligent microcontroller system
Features:
✅ Auto-on during power failure or fire trigger
✅ Auto-off after 3 hours to preserve battery
✅ Smart energy monitoring and thermal regulation
Protection against:
🔋 Overcharge
🔋 Deep discharge
🔋 Battery overheating
Integrated 6V 4.5AH Sealed Lead-Acid Heavy-Duty Battery
Delivers up to 3 hours of continuous illumination
Auto-recharges once AC power is restored
Designed for long battery life and minimum maintenance
Model: Lycan7559
Compact, durable body – engineered for fire zone reliability
80 Lux light output for high-penetration yellow beam
Supports wall or ceiling mounting
Fire panel and AC connectivity combined
✅ UL Certified
✅ NFPA Compliant
✅ Accord & RSC Approved
Built to meet stringent industrial and export safety requirements
Garment & Textile Industries
Chemical Factories & Warehouses
High-Density Storage Areas
Basements, Stairwells, and Emergency Paths
Commercial Buildings & Public Facilities
Two-Way Activation: Auto-on with AC failure or fire detection, even if AC is present
Fire Panel Integration: Triggers all lights in cascade mode for large zones
Microcontroller-Based: Maximizes battery health, minimizes risk
Proven in Bangladesh’s top industrial safety infrastructure
💡 ORASKA Lycan7559 – The Emergency Fog Light You Can Rely on When Power Fails or Fire Strikes.
| Product Size | 11 by 11 by 3.5 inch |
|---|---|
| Product Weight | 2260 Grams |
